5″ Monitor & PEUGEOT Rifter Reversing Camera Kit

Camera Compatibility:

CITROEN Berlingo MK2 (2008-2018)
CITROEN Berlingo MK3 (2018-Present)
PEUGEOT Partner MK2 (2008-2018)
PEUGEOT Rifter (2018-Present)
Fiat Doblo III [K9] (2022-Present)
Toyota ProAce City (2019-Present)
Opel Combo [E] (2018-Present)
Vauxhall Combo [E] (2018-Present)

Camera Specifications:

Image sensor: 1/3″ CMOS
Effective pixel: 733(H)x493(V)
TV Line: 700TV Lines
Night Vision distance: Approx.35ft
Waterproof rating: IP68
Viewing angle: 120°
Video system: PAL/NTSC
S/N Ratio: > 48dB
Current consumption: < 150mA
Minimum illumination: 0.1Lux/F=1.2
Power: DC 12V
Operating temperature: -20℃ to +70℃

Monitor Specifications:

* Screen size: 5 inchs
* Display format: 4: 3
* Resolution: 480*272 IPS
* Power supply: DC 12-24V
* Video system: NTSC / PAL auto switch
* Video Input: Dual video inputs, AV1 and AV2 (For reversing camera).
* With menu button, brightness/contrast/saturation adjustable.
* Operation temperature: -20℃ ~ 60℃
* Storage temperature: -20℃ ~ 60℃
